Link to Documents in Papyrus Model Repositories

Last time, we looked at searching for stuff in your Papyrus model repositories. What is better than searching for models and documents? Linking to them so that you don't have to search again.

The Kepler release of Papyrus has a facility for creating hyperlinks from shapes in diagrams to arbitrary documents in the local filesystem or anywhere on the Internet that is addressable by a URL. This is updated in the upcoming M2 milestone of the Luna release to support hyperlinking to documents in CDO model repositories. That's right, documents in model repositories. The Kepler release of CDO added support for storage of "file resources", text or binary, as CLOBs and BLOBs, respectively, in the database. As usual, I have recorded a short video demonstration of this new feature in action.

A brief demonstration of a new feature in Eclipse Papyrus M2 of the Luna release: hyperlinking to documents in CDO model repositories.

In brief, Luna M2 will have:

• the Model Repositories view now shows all resources in your repository, including non-Papyrus models and file resources. You can create and edit file resources in this view
• a refactored hyperlink dialog: all the different types of hyperlinks are now managed in a single tab, not in separate tabs
• in the hyperlink dialog, browse currently connected repositories to select a file resource ("document") or even a Papyrus model to link
• drag-and-drop documents and models from the Model Repositories view to a shape in a diagram to create hyperlinks
• create hyperlinks (by browse or drag-and-drop) to resources in a repository from models in other repositories or the workspace
• click a hyperlink in the pop-up action bar to open the linked document or model in the appropriate editor, opening the connection to the repository first, if necessary

See bug 415373 for the further details.
